Blank EcoSteel – The Safety Fencing System
for maximum safety and efficiency
Blank EcoSteel is an advanced industrial protective fencing system that offers proven impact resistance, rapid assembly, and high flexibility. It is used in sectors such as manufacturing, automation, and the automotive industry – wherever functional safety, standard compliance, and cost-effectiveness are critical.
Compliant & Safe
Exceeds DIN EN ISO 14120, meets safety requirements from risk assessments. Compatible with doors, locks, and Smart Components for efficient, auditable workplaces.
Robust
Maximum stability with minimal assembly effort. Reinforced mesh, solid posts, and base plates. Impact resistance over 1950 J – for continuous use in industrial environments.
Versatile
A system that can do more: EcoSteel combines two functions in one. Modularly expandable, with variable heights, RAL colors, and infills. A wide selection of panel fields – often directly from stock.
These partners trust EcoSteel
Features & Technical Data
Panels
Mesh size: 20 × 100 × 3 mm
Mesh opening: 17 × 97 mm
Heights: 20 × 100 × 3 mm
Standard widths*: 200 / 300 / 700 / 800
1000 / 1200 / 1500 mm
* Special width dimensions
Note on more standard widths for less costly and resource-intensive custom productions
Posts
Post base: 160 × 150 mm, folded, with multiple anchoring points
Post heights: 2200 / 2400 mm
Post cross-section: 40 × 60 mm
Industrial Robustness
- EcoSteel protects processes
3 mm wire thickness, 20 × 100 mm mesh. Stable and precisely welded. - Standard panel heights 2050 mm & 2250 mm, optional special dimension range.
- Significant risk reduction. According to DIN EN ISO 14120
Data at a Glance
Modular Panel Fields – More Standard Options
Through a wide selection of mesh sizes, colors, and fastening options, Blank EcoSteel offers maximum configurability without the need for custom productions. You can find our current flyers and videos for download and viewing.
| Feature | Details |
| Impact Resistance | > 1950 J |
| Height of Mesh Elements | 2050 and 2250 mm (other heights possible) |
| Widths of Panels | 200 – 1500 mm (modularly selectable) |
| Mesh Size | 20 x 100 mm |
| Wire Diameter | Horizontal: 5 mm, Vertical: 4 mm |
| Colors (RAL) | 9011, 1021, 7035, 5012 – other RAL shades possible |
| Surface | Powder-coated or galvanized |
Mesh Panels
Electro-welded mesh panels offer optimal protection with high transparency. They allow a clear view of system areas and facilitate maintenance and monitoring.
Posts & Ground Anchoring
The robust steel posts with a 60×40 mm cross-section and solid base plate guarantee a firm stand. Optionally available with flexible anchors for challenging ground conditions.
Connection Systems
Thanks to its modular design, Blank EcoSteel can be assembled quickly and securely – connection elements are pre-assembled, adaptable, and combinable with accessories such as doors or locks.
Color Selection
The system is immediately available in four standard colors. Other RAL shades are possible upon request – matching your corporate identity or the color concept of your facility.
Infills – Functional Diversity
In addition to mesh infills, Blank EcoSteel offers three other infill variants for special requirements: All infills are fully compatible with the EcoSteel modular system and can be flexibly combined or retrofitted.
PETG Infill
- UV-resistant, suitable for laser workstations
- Highly impact and scratch resistant
- ISO EN 25980 compliant
- Protection against sparks and optical radiation
Polycarbonate Infill (PC)
- Extremely break-resistant
- Available transparent or tinted
- Suitable for high mechanical stress
Sheet Metal Infill
- Completely closed – ideal for privacy requirements
- Protection against dust, chips, sparks
- Highest structural strength
Doors, Gates & Single-Source Handling
For secure yet flexible access, we offer a variety of door solutions that can be optimally integrated into our safety fencing system. Depending on the requirements for space, operation, and safety level, the following variants are available to you:
Portfolio
Single & Double Doors:
The classic solution for regular access.
Multi-fold Doors:
Space-saving and ideal for large openings.
Sliding Doors:
For convenient operation even in confined spaces.
Swing Flaps:
For quick, uncomplicated passage.
Lift Gates:
For automated and particularly comfortable solutions.
(mechanical, electrical, or pneumatic)
Smart Components
for efficiency, order, and structured workplaces
In modern manufacturing environments, order, safety, and efficiency are considered indispensable fundamental principles – both in terms of operational processes and in the context of normative requirements such as DIN EN ISO 45001 or ISO 14644. With Blank EcoSteel Smart Components, these requirements are met directly at the production line.
The modular accessory system is the functional extension of the EcoSteel safety fencing system. It enables structured workplace design, which is ideal for 5S standards, LEAN processes, and quick changeovers. All without modifications to the system itself. The Smart Components are fully compatible with all mesh variants and heights of Blank EcoSteel. They can also be retrofitted, are upgradeable at any time, and thus offer maximum flexibility for changing production requirements – entirely without system modifications.
Advantages of Smart Components
- Structured workplace design directly on the safety fence
- Supports 5S and LEAN principles
- Tool-free assembly on the fence mesh
- 360° rotatable for flexible use
- Auditable solution according to ISO specifications
- Hygienic – Ideal for cleaning & disinfectants
- Retrofittable & compatible with all EcoSteel systems
Application Examples
- Assembly lines in the automotive industry
- Logistics areas with high changeover effort
- Cleanrooms & hygienically sensitive areas
- Special machines with regular tool changes
- Safety-relevant zones with auditable processes
